Flush

Detection distance

10mm

DC

6-36

VDC

NPN

NO

IM30-10-DNA-C3

NC

IM30-10-DNB-C3

NO+NC

IM30-10-DNC-C3

PNP

NO

IM30-10-DPA-C3

NC

IM30-10-DPB-C3

NO+NC

IM30-10-DPC-C3

Two wire

systerm

NO

IM30-10-DLA-C3

NC

IM30-10-DLB-C3

AC

90~250

VAC

SCR control-lable silicon

NO

IM30-10-ACA-C3

NC

IM30-10-ACB-C3

NO+NC

Relay output

Non-

flush

Detection distance

15mm

DC

6-36

VDC

NPN

NO

IM30-15-DNA-C3

NC

IM30-15-DNB-C3

NO+NC

IM30-15-DNC-C3

PNP

NO

IM30-15-DPA-C3

NC

IM30-15-DPB-C3

NO+NC

IM30-15-DPC-C3

Two

wire system

NO

IM30-15-DLA-C3

NC

IM30-15-DLB-C3

AC

90~250

VAC

SCR Control-lable

silicon

NO

IM30-15-ACA-C3

NC

IM30-15-ACB-C3

NO+NC

Relay output

Output current

DC

200mA

SCR/ Relay

300mA

Output voltage drop DC/AC

DC＜3V, AC＜10V,  DC two wire＜3.9V

Consumption current

DC12V＜8mA,  DC24V＜8mA,  AC＜10mA

Standard detected object

18*18*1 A3 Iron

Repeated precision

0.05

DC/AC Response frequency

200Hz/10Hz

Working environment temperature

-25°C~+65°C

Insulation resistance

50MΩ

Shell material

Metal

Protection grade

IP67

Altemative model at home and abroad

E2E-X18ME1-MI
