CXS2P-100 Mini ATS 2P 4P 100A Automatic Transfer Switch Electrical Selector Switches Dual Power Switch Din Rail Type ATS 100A
| ITEM NO. |
CXS |
| Rated current Ie(A) |
16A, 20A, 25A, 32A, 40A, 50A, 63A,100A |
| Installation |
Din rail |
| Rated insulation voltage Ui (V) |
AC690, 50HZ |
| Rated working voltage Ue (V) |
AC400, 50HZ |
| Rated impulse withstand voltage (KV ) |
8KV |
| Poles |
2P 3P 4P |
| Weight (KG) |
1.7 2.1 2.6 |
| Connecting and breaking |
6.0Ie 1.05Ue cosØ=0.50±0.05, 50 times |
| Operating performance |
2.0Ie 1.05Ue cosØ=0.80±0.05, 6000 times |
| Rated limited short-circuit current Iq |
50KA |
| SCPD (FUSES ) |
RT16-00-63A |
| Control circuit |
Rated supply voltage Us: AC220V, 50HZ.
Working condition:85% Us~110% Us
|
| Ancillary circuit |
Two isolated relays, each relay with 2 groups of passive
switch contact. Contact capacity: AC220 50Hz, Ie=5A
|
| Switching time |
<50ms |
| Action time |
<50ms |
|
