Products > SOLID STATE RELAY > solid state relay ssr > DC to DC

Product name : DC to DC

Item : 201512615259

Enlarge Image

Back

←[Previous Product] [Next Product]→

Details:

solid state relay DC to DC 24-220VDC 3-32VDC SSR

load current	10A,15A,20A,25A,30A,40A
load current	50A,60A,80A,100A
load voltage	24-220VDC
input voltage	3-32VDC
input current	DC5-25mA
voltage drop	≤2.3V
leakage current	≤2mA
on-off time	≤10mS
dielectric strength	2000VAC
insulation resistance	1000MΩ500VDC
ambient temperature	-30~+75℃
mounting method	bolt fixed
working indication	LED
weight	90g(10A,25A) 135g(40A and above)
