外形尺寸
OVERALL DIMENSIONS
|
 |
| |
检测距离 DETECTION DISTANCE 15mm
|
|
埋
入
式
F
l
u
s
h
|
直流
DC
10-
30
VDC
交流
AC
90-
250
VAC
|
NPN
|
NO
|
IMF10-15-DNA
|
|
NC
|
IMF10-15-DNB
|
|
NO+NC
|
IMF10-15-DNC
|
|
PNP
|
NO
|
IMF10-15-DPA
|
|
NC
|
IMF10-15-DPB
|
|
NO+NC
|
IMF10-15-DPC
|
|
二线制
two wire
system
|
NO
|
IMF10-15-DLA
|
|
NC
|
IMF10-15-DLB
|
|
SCR
可控硅
Control-
lable
silicon
|
NO
|
IMF10-15-ACA
|
|
NC
|
IMF10-15-ACB
|
|
NO+NC
|
|
| 继电器输出Relay output |
|
| |
检测距离 DETECTION DISTANCE 20mm
|
|
非
埋
入
式
F
l
u
s
h
|
直流
DC
10-
30
VDC
交流
AC
90-
250
VAC
|
NPN
|
NO
|
IMF10-20-DNA
|
|
NC
|
IMF10-20-DNB
|
|
NO+NC
|
IMF10-20-DNC
|
|
PNP
|
NO
|
IMF10-20-DPA
|
|
NC
|
IMF10-20-DPB
|
|
NO+NC
|
IMF10-20-DPC
|
|
二线制
two wire
system
|
NO
|
IMF10-20-DLA
|
|
NC
|
IMF10-20-DLB
|
|
SCR
可控硅
Control-
lable
silicon
|
NO
|
IMF10-20-ACA
|
|
NC
|
IMF10-20-ACB
|
|
NO+NC
|
|
| 继电器输出Relay output |
|
|
输出电流
Controloutput
|
DC
|
200mA
|
|
SCR/继电器 Relay
|
500mA
|
|
输出电压降Output voltagc dropDC/AC
|
直流(NPN PNP)型3V以下、二线型：3.9V以下、交流AC 10V以下 DC<3V、AC<10V
|
|
消耗电流Consumption current
|
直流(NPN PNP)型DC 12V时8mA、24V时15mA、交流AC 10mA以下DC<15mA、AC<10mA
|
|
标准检测物体Standard detected object
|
45X45X1(A3铁iron)
|
| 重复精度Repeated precision |
0.05
|
| 响应频率DC/AC |
100Hz/15Hz
|
| 工作环境温度Working environment temperature |
-25℃～+75℃
|
| 绝缘电阻Insulation resistance |
50MΩ
|
| 外壳材料Shell material |
ABS树脂Resin
|
| 防护等级Protection grade |
IP67
|
| 可替代国内型号Altemative model at home and abroad |
TL-N20M口
|
