| MODEL |
BEN10M-TFR |
BEN5M-MFR |
BEN500-DFR |
|
|
though beam type |
retroreflect type |
diffuse type |
| Detect distance |
10m |
0.1-5m |
500mm |
| Detect target |
Opaque materials of Min 16mm |
Opaque materials of Min 60mm |
Transpqrent, translucent, opaque materials |
| Hysterisis |
------------ |
--------------- |
20% Max, at detecting distance |
| Response time |
Max 20mS |
Max 20mS |
Max 20mS |
| Power voltage |
AC 24-240V DC 24-240V |
AC 24-240V DC 24-240V |
AC 24-240V DC 24-240V |
| Sensitivity |
------------ |
---------------- |
Adjustable by VR |
| Operating mode |
Light on/off select by slide switch |
Light on/off select by slide switch |
Light on/off select by slide switch |
| Control output |
Relay output |
|
|
| Protection |
IP54 |
IP54 |
IP54 |
| |
|
|
|
